Drone Surveillance System
When you need a tactical autonomous surveillance system with long flight endurance, the TD1 will provide a tactical aerial surveillance system.
The TD-1 is an advanced DRONE Surveillance System that provides real-time day and night video stream via Ground Control Station. Complete autonomous operation with long endurance of above 60Mn and low weight make the TD1 the best operational and cost-efficient solution.
Features
- Endurance Up to 80 min.
- Simple, compact, lightweight & modular design
- Ruggedized, dust and rain proof
- Designed for ISTAR missions
- 2 rechargeable batteries
- Dual day & night camera
- GCS: 10” ruggedized touch screen computer
- Operation console with joysticks and controllers
- Transportation 1 rugged suitcase / backpack
- Weight 4 Kg TOW
- Dimensions 60 cm x 60 cm x 30 cm
- Wind Limit 15 knots / 28 Km/h max.
- Operating Altitude 100 ft. – 1000 ft. / 30 m – 300 m AGL
- Operating Temperature -10⁰C to +50⁰C / -50⁰F to +122⁰F
- Storage Temperature -15⁰C to +60⁰C / -60⁰F to +140⁰F
- Battery Charger Option by Car and std. socket 220V/110V
- Propulsion System 4 electric motors and propellers
- Communication Data uplink, telemetry and video downlink
Applications
- Short rage real time situational awareness
- Surveillance and Monitoring
- Search and rescue
- Perimeter Security
- Fire control
- Convoy following
